Heat Transfer Label
Characteristics
| Brand Name | Jiangchuan |
| Voltage(V) | 220/110V |
| Temperature range(°C) | 0-399 |
| Time control(S) | 0-999 |
| Printing area(CM2) | 38X38（15''X15'') |
| Power(KW) | 2.2kw |
| Gross weight(KG) | 32kg |
| Packing Dimensions(CM) | 72*48*39cm |
| Warranty | 1 Year |
| MOQ | 1 Set |
Heat transfer temperature and time settings
1.Sublimation heat transfer - Temperature: 220 C, Time: 20 seconds
2.film heat transfer - Temperature: 160 to 180 C, time: 8 to 10 seconds
3.foam Tang - temperature: 140 ~ 160 C, time: 5-8 seconds
4.hot drilling - temperature: 180 C, Time: 10 to 12 seconds
Operation Steps
1.Plug in the power supply, turn on the main power switch (red), the indicator light is on. Note: The whole machine must have a suitable protective ground wire);
2.Adjust the temperature controller to the required temperature and set the required time;
3.After adjusting the temperature and time, wait for the machine to heat up.
4.After the temperature rise is completed, the temperature meter OUT1 light goes out and then flashes automatically. (when keeping warm)
