Description
Technical Parameters
Roller Heat Press Machine Suppliers
Parameters Details
| Brand Name | Jiangchuan |
| Printing/Roll width | 3200 mm 125.9 inch |
| Roller diameter | 420 mm 16.5 inch |
| Blanket width | 3150mm 124inch |
| Voltage | 220V /380V |
| Other Voltage | Custom voltage by your special order. |
| Rated output | 48KW |
| Speed | 0-6m/min |
| Weight | 4000KG |
| Packing size | 420x174x180cm |
| Feeding Method | Top feeding |
| Other Size | Available |
| Air Compressor Required | Required |
| Blanket Material | Nomex:Gigh temperature resistance |
| Drum Surface | Chrome:high hardness and abrasion performance |
| Drum | Oil 100% |
| Temperature range(℃) | 0-399 |
| Time range(S) | 0-999 |
| Scope of Delivery | Roller heat transfer machine, Power cable without plug, some electronic spare parts for free |
| Note | Custom size by your special order. |
| Customized machine to work with different power supplies | |
| Warranty | 1 Year |
| MOQ | 1 Set |
Feature
1.Belt feeding system with independent drive for feeding roll fabric
2.Oil heated drum system assures uniform heat across the width of the cylinder and the lowest possible power consumption.
3.Electro pneumatic belt steering system
4.Safety bar with reverse control
5.Cool down timer
6.Exit cooling conveyor
7.Automatic paper separator bar eliminates ghosting caused by paper shifting or fabric shrinkage
8.Exit cooling conveyor cools and take printed parts to the back side for stacking
