Description
Technical Parameters
Rotary Heatpress
Characteristics
| Media Width | 1700 mm 67 inch |
| Diameter of Drum | 420 mm 16.5 inch |
| Transfer Speed | 0-8m/min |
| Reated power(KW) | 30KW |
| Voltage(V) | 220/380 |
| Fed-in media | Transfer paper,fabric,protective paper |
| Voltage / Heating Power | 220/380/440/480 Three phase four wire |
| Machine Size | 2670*1570*1700mm |
| Packing Dimension | 2840x1680x1900mm |
| Weight | 2200 KG |
| Note | Custom size by your special order. |
| Customized machine to work with different power supplies | |
| Recommend compressor | Required |
1.Advaced technology of Electrical control ,blanket can seperate from drum by manual/automatic.
2.Motor drive blanket goes back to drum and enter
3.Blanket has automatic alignment function
4.Transfer by 150Meter-300meter/hour(590inches-1180inches)
5digital thermostatically controlled,motor digital adjustment,accuracy can up to （±1-2℃）
6.Chrome drum technology,hardness,rarely to getting apart from drum. Best transfer effect.
7.Advance heating technology,circuit system,even heating.
8.Highten oil tank,turn off valve automatically. Easy to change thermal oil,never explosion
